AIRSTAGE SINGLE-ROOM MINI-SPLIT SYSTEMS Wall Mounted Extra Low Temp Heating 09LMAH1

XLTH; Extra Low Temperature Heating

Indoor Unit Systems: ASUH09LMAS, Outdoor Unit: AOUH09LMAH1

Indoor Unit:
ASUH09LMAS
Outdoor Unit:
AOUH09LMAH1
Downloads:
Operation Manual
Warranty
13.0 HSPF
  • INVERTER 7 year compressor 5year parts Warranty. Refrigerant R410A ENERGY STAR®

  • ENERGY STAR* Qualfied
  • Highly Efficient
  • Powerful Heating Down to -15°F Outdoor Temperatures
  • Base Freeze Prevention
  • Quiet Operation
  • Inverter Technology
  • Wireless Remote Controller included
  • Washable Panel Filter

Cooling  11,500 BTU/h
Heating  16,000 BTU/h

Specification
Power Source Voltage/Frequency/Phase 208-230/60/1
Capacity Cooling BTU/h 9,000(3,100~12,000)
Heating 12,000(3,100~22,000)
HSPF BTU/hW 14.0
SEER BTU/hW 33.0
EER Cooling/Heating W/W 18.0
Operation Range Cooling °F(°C) 14~115 (-10~46)
Heating -15~75 (-26~24)
Moisture Removal Pt./h(l/h) 2.6 (1.2)
MAX.CRT.BKR A 15
Air Circ. C.F.M. Hi (m³/h) 489 (830)
Medium 400 (680)
Low 341 (580)
Quiet 224 (380)
Noise Level Hi dB(A)
15RLS3
42/41
Medium 37/35
Low 32/31
Quiet 23/23
Outdoor Fan Speed RPM 989/1,082
Outdoor Noise Level dB(A)
Clg/Htg
42/47
Current Cooling A 2.5/9.4
Heating 3.3/10.0
Power Use Cooling kw 0.50/0.85
Heating 0.66/1.93
Fan Speeds Stage 4+Auto
Air Direction Horizontal Automatic
Vertical Automatic
Air Filter Washable
Connection Method Flare
Combined Min.Lgth Ft (m) 10 (3)
Max.Lgth 66 (20)
(pre-charge: 49’)
Max. Vertical Diff. Ft (m) 49 (15)
Conn. Pipe Diameter Indoor Inch Suc.3/8
Outdoor Dis.1/4
Net Weight Indoor lbs.(kg) 31 (14)
Outdoor 86 (39)
Dimensions Height Indoor Inch 11-5/8
mm 295
Outdoor Inch 24-7/16
mm 620
Width Indoor Inch 37
mm 940
Outdoor Inch 31-1/8
mm 790
Depth Indoor Inch 10-5/8
mm 270
Outdoor Inch 11-7/16
mm 290
Refrigerant (Global Warming Potential) R410A
Scroll
Dimensions

Indoor Unit: ASU9RLS3

Indoor Units: Dimensions

Outdoor Unit: AOU9RLS3H

Outdoor Units: Dimensions
