Halcyon™ SINGLE-ROOM MINI-SPLIT SYSTEMS 115V Wall Mounted RL2 Series Entry Level 12RL2

Halcyon™

Indoor Unit Systems: ASU12RL2, Outdoor Unit: AOU12RL2

Indoor Unit:
ASU12RL2
Outdoor Unit:
AOU12RL2
Downloads:
Manuals
Warranty
16.0 SEER
  • INVERTER 7 year compressor 5year parts Warranty. Refrigerant R410A

  • 115V Inverter
  • Quiet Operation
  • Wireless Remote Controller
  • Washable Panel Filter
  • Smart System: Auto Mode
  • Humidity Control

Cooling  12,000 BTU/h
Heating  14,000 BTU/h

Specification
Power Source Voltage/Frequency/Phase 115/60/1
Capacity Cooling BTU/h 12,000(3,100~12,500)
Heating 14,000(3,100~16,000)
HSPF BTU/hW 9.0
SEER BTU/hW 16.0
EER Cooling/Heating W/W 10.0/11.5
Operation Range Cooling °F(°C) 15~115 (-10~46)
Heating 15~75 (-10~24)
Moisture Removal Pt./h(l/h) 3.8 (1.8)
MAX.CRT.BKR A 20
Air Circ. C.F.M. Hi (m³/h) 436 (740)
Medium 353 (600)
Low 265 (450)
Quiet 191 (325)
Noise Level Hi dB(A)
15RLS3
43/43
Medium 38/38
Low 33/33
Quiet 23/23
Outdoor Fan Speed RPM 860
Outdoor Noise Level dB(A)
Clg/Htg
51/51
Current Cooling A 10.9
Heating 11.0
Power Use Cooling kw 1.20
Heating 1.21
Fan Speeds Stage 4 + Auto
Air Direction Horizontal Manual
Vertical Automatic
Air Filter Washable
Connection Method Flare
Combined Min.Lgth Ft (m) 10 (3)
Max.Lgth 66 (20)
(pre-charge: 49’)
Max. Vertical Diff. Ft (m) 47/48
Conn. Pipe Diameter Indoor Inch Suc. 3/8
Outdoor Dis. 1/4
Net Weight Indoor lbs.(kg) 16 (7)
Outdoor 69 (31)
Dimensions Height Indoor Inch 10-5/16
mm 262
Outdoor Inch 21-1/4
mm 540
Width Indoor Inch 32-9/32
mm 820
Outdoor Inch 26
mm 660
Depth Indoor Inch 8-1/8
mm 206
Outdoor Inch 11-11/32
mm 290
Refrigerant (Global Warming Potential) R410A
Scroll
Dimensions

Indoor Unit: ASU12RL2

Indoor Units: Dimensions

Outdoor Unit: AOU12RL2

Outdoor Units: Dimensions
